商品の詳細:
お支払配送条件:
|
| Port size: | 1" | Working medium: | water, liquid, air, light oil (viscosity≤20cst) |
|---|---|---|---|
| Medium temperature: | -5 ~ 80℃ | Working pressure: | 0 ~ 7 bar |
| Working type: | semi direct acting | Valve body material: | PA66 (from German) |
| Sealing material: | NBR (-5 ~ 80℃) | Interface: | G thread, NPT thread |
| Working voltage: | AC220~240V, AC110V 50/60Hz, DC24/12V | Power consumption: | DN15~25 AC20VA DC20W, DN32~50 AC50VA DC35W |
| Structure: | Diaphragm | Function: | electromechanical valve for liquid or gas |
| Options: | LED light connector | Working pressure range: | 0.3 ~ 8 bar |
| Power consumption (YSA-series): | AC25VA DC13W | ||
| ハイライト: | 1インチ プラスチック電磁弁,2方 水用電磁弁,空気・水用電磁弁 |
||
| 用途 | 一般 |
| ポートサイズ | 1" |
| 保証 | 3年 |
| 電源 | 電磁 |
| 温度範囲 | 媒体温度、常温 |
| タイプ | その他のバルブ |
| 構造 | ダイヤフラム |
| 媒体 | 水 |
| 認証 | CE ISO ROHS |
